As part of Arctic Semiconductor’s suite of world’s first multi-standard ultra-wide-band RF transceivers, IceWings’s quad-channel supports all 5G/4G bands operating from 600MHz up the frequency of 7.2GHz as well as WiFi 6/6e/7 bands. IceWings’s multi-standard feature design provides much needed design flexibility and scalability to customers and manufacturers.
Quad Tx/Rx
Analog RF technology
Analog IQ
Interface with Baseband SoC
600MHz to 7.2GHz
Wide-band single-ended RF ports
Programmable BW
Enabling diverse applications
Wide Band
4 Rx Paths
Can be used for observation reducing complexity in TDD modes
Integrated
TWO SYNTHESIZERS
Low Phase noise fractional synthesizers supporting TDD, FDD and two 2×2 in TDD
Reduces the number of RF switches in multi band designs
Integrated LNA and Pre-amplifiers
FR1 support: 5/10/20/40/80/100/160/200/400 MHz Channel BW
FR2 support: : 400MHz, IF frequency 3.3GHz-7.12GHz
Benefits
Power consumption
Lowest power consumption with highest level of integration, accelerating the deployment of 5G.
Multi-standard support
Support for a wide range of wireless standards with a flexible scalable interface design.
Scalability
Programmable BW for various FR1 and FR2 applications including small cells, private networks, Enterprises, IoT, and macro cells.
Performance
Complying with 5G NR, WiFi, WiFi 6/7 and 4G LTE specifications and offering superior performance in signal quality, noise, linearity, and power consumption due to the inherently innovative architecture.
